AL-VXLED Recessed LED Modular

• VX LED for 500 x 500 and 600 x600 grid ceiling
• Microprism optic or matt opal, fully recessed body with no protrusion below Ceiling grid line
• Glare-free lighting -UGR19
• The balanced contrast creates a pleasant atmosphere, illumination that complies with current standard
• LG7 high light output, balanced with good quality lit environment
• It eliminates dark ceilings
• Fits exposed T-bar 15 or 25mm
• Housing fabricated from cold-rolled steel high-reflectance powder coated matt white Conforms to *EN 12464-1 UGR<19 LG7:2015 <3000 cd/m2 @ 65˚
• Microprismatic central optic for glare-free illumination
• Opal central optic for enhanced light transmission and perfect uniform illuminations
• Air handling to 25 L/S
• Tridonic LED modules
• Tridonic LED driver
• TPa
• L90/60,000hrs B10
• 3 Step MacAdam Ellipse
• Casambi Wirefree Controls also available
